Interior — 3D-printable BMW parts

Cup holder developed and physically installed for a first-generation BMW 1 Series interior. The retained files are the latest creator-supplied right- and left-hand supported variants; earlier revisions are preserved in the source archive but are not submitted. Use a heat-resistant cabin material and confirm local clearance before driving.

Direct replacement cap for the automatic-headlight rotary switch used in BMW E82 and E88 1 Series, E90/E91/E92/E93 3 Series, and E84 X1 interiors. The keyed hex and rotation stop reproduce the functional interface, and the creator shows the printed knob installed. Reuse the original switch mechanism; no complete headlight-switch assembly is included.

Three-piece cup-holder assembly tested in a 2010 BMW E87. It relocates the drink above the original low cup recess so taller containers can be used without the armrest interfering. The retained package contains the adapter, bridge, and cup cradle. Use a heat-resistant cabin material and verify secure engagement before driving.

Two-piece removable cup holder for early BMW 1 Series door pockets. A separate interference-fit hook supports the holder in the door pocket; the creator sized it for takeaway cups and drinks cans and supplied a physical print photograph. Print in PETG or ABS for cabin heat resistance and confirm retention before driving.

Two-piece replacement for the left dashboard air-vent position in a BMW E87, combining the vent housing with a round gauge/display holder. The creator's gallery shows the assembly installed in the vehicle. Confirm the instrument diameter and preserve safe driver visibility before installation.

Cup holder and 50-cent shopping-token recess for left-hand-drive first-generation BMW 1 Series centre consoles that lack the factory holder. The creator installed the printed assembly with double-sided tape and reports secure use. Both the single-piece model and the split top/bottom alternative are retained. PETG or ABS is recommended for summer cabin temperatures.

Phone-mount bracket for the factory accessory cup-holder socket in BMW E81, E82, E87, and E88 interiors. The current creator photographs show the bracket installed with a circular magnetic phone interface and also show the loose physical print. Only the bracket is included; choose compatible phone hardware and confirm that the device does not obstruct controls or driver visibility.

Measured replacement door-lock knob for a BMW F20 1 Series. The creator modeled the original knob directly, printed it, and shows the replacement installed on the door lock pin. Confirm the bore and free lock movement before use.

Press-fit cover for the deteriorating climate-control rotary knob in a 2013 BMW F20 1 Series. The creator refined the fit through five iterations and shows the cover installed over the original knob. Use a cabin-temperature-resistant material and check that the control rotates without binding.

Low-profile 17 mm ball mount developed for the BMW F20 1 Series center-console side panel. The creator attaches it with double-sided automotive foam tape, shows it installed with a phone holder, and reports no problems in use. Print in ASA, ABS, or another cabin-temperature-resistant material and keep the device clear of controls and driver sight lines.

Two-piece key tray shaped for the BMW F20 and F21 1 Series cup holder. The body and upper tray are bonded after printing, and the creator shows the assembly installed both empty and holding a key. Use a heat-resistant cabin material and verify that the tray remains secure before driving.

Two-piece clamp eyelet that repairs a broken parcel-shelf lifting cord on a BMW F20 LCI II without replacing the complete shelf. The creator shows the installed repair and supplies an original-project file alongside the printable mesh. Cut the cord only after confirming final length; use fine layers, verify that the clamp closes fully, and add adhesive if needed.

Adapter that clips around the BMW F20 center ventilation grille and accepts the creator's screw-mounted phone cradle. Multiple source photographs show the current revision installed. Use ASA, ABS, nylon, or another high-temperature material; inspect the clips for cracking and ensure the phone does not obstruct controls, airbag deployment, or driver visibility.

Cup-holder phone stand with a Lightning-cable passage, documented by the creator for BMW F20 1 Series and F30/F31 3 Series interiors. The gallery shows the stand installed, holding phones, and routing the charge cable. Add a thin foam or rubber liner as suggested, use a heat-resistant cabin material, and confirm secure phone retention before driving.

Custom-fitted charging pad for the center-console storage recess of the BMW 1 Series F70 (2024 onward). The creator shows the finished pad, its underside with the charger electronics, and the completed installation in an F70. It requires an INIU 15 W Qi charger, careful disassembly, and a shortened USB-C lead soldered to the charger PCB. Use a heat-resistant material, have the electrical work performed by a competent person, insulate and strain-relieve all connections, and stop use immediately if the charger or phone overheats.

Drop-in organizer tray for the deep center-armrest storage compartment of the BMW 1 Series F70 (2024 onward). Dedicated sections hold coins, keys, charging cables, and a French motorway toll tag. The creator's photographs show the printed organizer installed in the armrest and loose for inspection. Use a cabin-temperature-resistant material and confirm that the armrest closes and latches normally without pinching cables.

Cup-holder insert developed and physically used in a 2016 BMW M2 F87 to keep narrow bottles upright. The source shows the printed insert installed beside a bottle. Print in PETG, ASA, ABS, or another cabin-temperature-resistant material and confirm the bottle remains secure without obstructing nearby controls.

Replacement slider for the factory BMW wireless-charging cradle that increases usable phone length to approximately 168 mm. The creator documents F2x, F3x, F8x, and I01 cradle compatibility and shows the printed part installed and measured. Print in PETG, ASA, ABS, or another cabin-temperature-resistant material; verify latch engagement, charging operation, and secure phone retention before driving.

Cup-holder insert for 330 ml beverage cans in BMW F22 and F87 interiors. The creator uses it in an F87 M2 and shows both the empty insert and a can seated in it. Print in PETG, ASA, ABS, or another cabin-temperature-resistant material and confirm the can remains stable without obstructing nearby controls.

Cup-holder insert for 250 ml beverage cans in BMW F22 and F87 interiors. The creator uses the matching design in an F87 M2 and provides installed physical views. Print in PETG, ASA, ABS, or another cabin-temperature-resistant material and confirm the can remains stable without obstructing nearby controls.

Cup-holder extension designed and physically installed in a BMW F22 2 Series to move large 32-ounce cups clear of the dashboard while retaining the original recess as small-item storage. Plain and roundel variants are included. The creator reports good retention with a small shim and uses heat-resistant PETG-CF. Verify fit, cup stability, and clearance from controls before driving.

Replacement linkage between the rear center-console vent thumbwheel and airflow flap on BMW F45/F46 Active Tourer and Gran Tourer, including pre-LCI and LCI. Remove the vent assembly for access, verify linkage orientation, and use a cabin-heat-resistant material.

Replacement hook that retains the cargo cover in position on the BMW F45 2 Series Active Tourer. Creator photographs show the physical hook installed; compare mounting orientation and clearances before fitting.

Four support-free mounting-base variants that clip into the small center-console storage pocket of BMW F45/F46 models. Includes fixed and rotating plates; rotating versions use an M5 nut and 12–20 mm bolt. Use PETG, ASA, or ABS rather than ordinary PLA.

Organizer tray for the compartment beneath the armrest in right-hand-drive BMW F45 Active Tourer and F46 Gran Tourer models. The source photograph shows the printed tray installed; this fitment is RHD-specific.

Flexible replacement for BMW rubber buffer 51466967605, creator-tested on an i3 and catalogued for F45, E81/E87, F20/F21, I01, and X1 E84. Print in approximately 85A TPU and cut out the temporary support tab after printing. Within the combined E8x generation, documented fitment is E81/E87 only.

Short adapter ring that centers narrow energy-drink cans in the factory cup holder of BMW F45 Active Tourer and F46 Gran Tourer models. The creator physically tested the reduced-height ring and photographed it installed.

Round organizer insert designed specifically for the factory cup holder in BMW F44 2 Series Gran Coupe models. It provides five coin slots, a BIC-lighter pocket, and an open storage compartment. The creator recommends PETG for cabin heat resistance; verify the approximately 80.4 mm outside diameter against the vehicle before printing.

Replacement clip for BMW door-sill/entry trim panels. The creator explicitly lists E21, E30, E36, E39, E46, E81/E82/E88, F20, E85 and related applications and identifies genuine BMW clip 51471840960. Verify the receiving-hole and trim thickness before fitting.

Working replacement retaining clip for the manual window crank of a 1982 BMW E21 320i. The creator reports the reinforced full-base iteration stays installed; other E21 crank variants were not claimed. Print solid and verify positive crank retention before use.

Printable M-Technic-style shift-knob replica documented for BMW E21 and E30. The source shows a finished physical print and provides sanding and polishing instructions. Verify selector-shaft engagement and secure retention before driving; this is not represented as an original BMW component.

Replacement expanding nut for securing front trim, grille and valance pieces on the BMW E21. The creator physically fitted the part and recommends flexible, heat-resistant PETG at full infill. Confirm hole diameter, screw engagement and trim retention.

Adapter for fitting most 6.5-inch speakers at the factory 4×6 rear-shelf positions of a 1981 BMW E21 320i without cutting new holes. The creator reports successful physical fit and sound. Check magnet depth, shelf clearance, fastener security and wiring before installation.

Replacement upper outer plastic cover for BMW E21 Recaro seats. Mirror the geometry for the opposite side. BMWFans identifies 52101877057 as left and 52101877058 as right across E21 variants; verify seat type, side and mounting points before fitting.

Two replacement seat-rail grommets tested on a European July 1982 BMW E21 323i. The filenames reproduce the two catalog shapes for BMW 52101807432 and 52208238999. Confirm seat-rail version, market and grommet position before installation.

Replacement cable holder corresponding to BMW 61131267476. The creator notes that ABS prints are less flexible than the original and accept a smaller loom or hose. RealOEM and BMWFans list the holder for E21 among many classic BMW applications; only E21 is linked here because the source does not enumerate chassis.

Dimensioned replacement wiring clip for BMW E21, E28 and E30, physically shown in use. BMWFans identifies the two creator-listed catalog applications as cable clamp 63121364431 and clamp 61131362825. Use heat-resistant material and verify loom diameter and mounting-hole retention.

Replacement trim ring or rosette for the manual sunroof handle on BMW E21, E28 and E30. The creator reports original-location fit and identifies BMW trim ring 54121867887, independently listed for E21 by RealOEM/BMWFans. Verify sunroof-handle version before fitting.

Replacement door-lock knob sleeve for BMW E21, E28 and E30, enlarged slightly for improved fit and physically demonstrated with the matching knob. The creator's two catalog references cover both sleeve and knob; neither is submitted here because public catalogs did not unambiguously map one number to this modified sleeve.

Replacement door-lock knob for BMW E21, E28 and E30, physically shown beside the original hardware and designed to work with the original or matching printable sleeve. The creator's mixed knob/sleeve catalog references are intentionally omitted. Verify pin diameter and retention.

Replacement moonroof slider developed and physically tested for a 1981 BMW E21 320is; the creator expects fit on E21 320 models equipped with a moonroof. Uses two M5 nuts instead of heat-set inserts. Confirm roof cassette, slider travel, nut capture and full open/close operation.

Dimensioned replacement glovebox damper pin for BMW E21, E28, E30, E31, E34, E38, E39, E46 and E60/E61. The creator identifies BMW pin 51161828956 and shows the physical result installed. Verify damper eye and panel thickness before fitting.

Dimensioned replacement switch knob for the Hella-style interior dome light used in BMW E12, E21 and E30. Physical prints are shown on the lamp. The creator-listed numbers identify complete lamp variants rather than this knob, so no parent-assembly number is submitted.

Press-on replacement cover for the original BMW E21 fuse box. The creator physically installed the ASA print and notes that the 220 mm model can be split and solvent-welded for smaller printers. Verify clearance, electrical isolation, heat resistance and secure retention.

Spinning replacement knob and glue-in collar made for the manual sunroof crank of a 1985 BMW E30. The creator shows the finished print on the crank. Dry-fit and keep adhesive away from the rotating shaft; no other year or chassis is claimed.

Replacement clip for retaining the E30 sunroof cables. The creator reports two years of use without an issue and recommends PETG. Verify cable capture and unrestricted sunroof travel after installation.

Replacement electrical connector housing for the classic Alpina vent gauge, designed around BMW 2.8 mm crimp terminals and compared with the original connector. Match terminal locking and pin order to the vehicle wiring before energizing.

Two-piece replacement cover and holder for securing the spare wheel in the E30 luggage compartment, shown physically installed. Confirm thread engagement and wheel retention before driving.

Replacement trim cover for exposed E30 seat-rail and seat-belt anchorage nuts. Match the installed fastener size and ensure the cover does not interfere with seat travel or belt hardware.

Inner and outer replacement covers for E30 headrest-post openings. The creator reports they function, though less precisely than the originals. BMWFans identifies the matching inner and outer covers as 52101838969 and 52108191245; verify position before fitting.

Straight and 90-degree reusable molds for rebuilding disintegrated overmolded BMW E3x electrical terminals with hot glue or a suitable insulating compound. The source includes a repair write-up; preserve terminal alignment and verify insulation and water resistance before connection.

Reinforced fastening repair for the E30 centre-side or B-pillar trim cover, copied from the original attachment and intended to be bonded to the broken cover. The creator-listed 51431933731/732 references are parent trim covers, so no OEM number is assigned.

Replacement headliner bracket supporting the dome light in an E30 coupe, physically compared with a failed original and installed. It is not claimed for convertible bodies; sedan fitment was not independently established. BMWFans confirms bracket 54121884483.

Replacement E30 ignition-lock trim ring reproduced from a broken original and shown fitted. BMWFans identifies ring 32311162057. Confirm steering-column trim version and do not obstruct key or lock-cylinder movement.

Replacement gear set for BMW E30 MotoMeter odometers, shown against and installed in a physical cluster. Gear numbers in the source are creator labels, not BMW component numbers.

Replacement gear set for BMW E30 VDO odometers, physically shown in the cluster. The common small gear duplicated by the MotoMeter source was removed from this submission during global hash preflight.

Replacement E30 front-strut wiring holder copied from the original and physically installed. BMWFans confirms cable holder 61131370421. Use heat- and abrasion-resistant material and verify wire clearance through full steering travel.

Reinforced replacement lower wiring cover for E30 door mirrors, copied from the original and physically fitted. The supplied geometry is LHD; mirror it for RHD. BMWFans confirms left/right LHD 51161937441/442 and RHD 51161937443/444.

Replacement E30 luggage-compartment clip for the factory wheel wrench, designed for the original mounting hole and physically shown retaining the wrench. BMWFans confirms clamp 51471933468.

Replacement side covers for BMW Reverse RDS, non-RDS, Bavaria and Business radios used in E30, E32, E34 and E36. The source shows physical fit and finish; BMWFans confirms covering cap 65126907823.

Replacement cap for the E30 luggage-compartment jack mount, copied from the original and physically installed. BMWFans confirms cover 51711916269.

Replacement fastener for E30 front-seat side covers, copied from the original and physically compared. It supports stock, sport and Recaro seats; BMWFans confirms push-button 52101906933.

Straight and 90-degree two-piece shells for repairing disintegrated 2.5 mm watertight terminals on BMW E30, E36 and E46. The source shows completed physical connectors. Bond with suitable RTV and verify terminal lock, polarity, insulation and sealing.

Replacement cap for E30 front seat-belt anchorage bolts, copied from the original and physically fitted on stock, sport and Recaro seats. BMWFans confirms covering cap 72111808464. Do not disturb or conceal a loose anchorage bolt.

Replacement plastic grommet used at E30 grille and rear license-plate mounting points, physically compared with the original. The creator also lists E36, E46, E90 and E92 applications; BMWFans confirms grommet 51131840154.

Left and right repair tabs for cracked E30 instrument-cluster mounting ears, test-fitted against an intact cluster and documented for screw or adhesive installation. Align the tabs in the dash before removing the damaged originals.

Replacement adjustment knob for BMW E30 M-Sport seats, physically shown as a finished print. Match the seat shaft and verify secure engagement before use.

Plain replacement cover designed for the sunroof motor opening of a 1987 BMW E30 325is and shown physically fitted. Use heat-resistant cabin material and verify screw and headliner clearance.

Resin-printable replacement pivot for the E30 convertible top-lock centering mechanism, physically compared with the original. BMWFans identifies the component as covering for centering bolt 54311971255. Verify pivot movement and roof latching before driving.

Smooth replacement covers for the MOMO K2006 steering-wheel hub and the separately measured Alpina leather hub, physically printed and fitted on E30. Select the correct file and verify steering-column clearance.

Short reinforced replacement lever for the brittle E30 hood-release handle, physically installed with a 4 mm or #8 screw and locknut. Print solid around the pivot and confirm reliable hood release before closing the hood.

Replacement slotted screw for retaining E30 seat-mechanism covers. The creator printed and tested revision 3.1 with a deeper screwdriver slot. Tighten only enough to retain the trim.

Replacement front engine wiring holder for E30 M20 and creator-listed E28/E34 applications, physically compared with the original. BMWFans confirms holder 11141716134. Use ASA, ABS or another engine-bay-rated material and inspect for heat distortion.

Bond-on repair for a broken outer lock section on E30 Touring luggage-compartment side panels, physically demonstrated on an iX panel and mirrorable for either outer side. The referenced latch and spring are separate components and are not assigned.

Replacement flexible tether for the E30 OBD-I diagnostic connector cap, approximated from a broken original and physically used by the creator. Print in a flexible, heat-resistant material and verify cap retention.

Replacement front-seat rail nut cap for E30 cars built before September 1985, copied from the original and physically compared. BMWFans confirms covering cap 52101913670.

Replacement front-seat rail nut cap for early cars from September 1985 onward and late-model E30, copied from and physically compared with the original. BMWFans confirms covering cap 52101941999.

Replacement sliding jaw for E30 and E28 sunroof mechanisms, copied from the original and physically compared. The source provides a load-oriented two-piece print option; BMWFans confirms sliding jaw 54121933550. Verify full sunroof travel before road use.

Replacement latch striker for E30 Touring luggage-compartment side covers, reproduced from the original and physically shown working. BMWFans confirms latch striker 51471947370.

Replacement E30 electric window-lifter spacer for mechanisms through April 1988, reproduced from the original and physically installed. BMWFans confirms spacer 51331919541; power-window mechanisms only.

Replacement E30 centre-console spacer that prevents lower trim deformation, copied from the original and physically installed. BMWFans confirms spacer 51161943121.

Replacement knob specifically for the late-model E30 manual sunroof crank, shown physically installed. Use cabin-heat-resistant material and verify that the crank turns and folds freely.

Replacement E30 exterior door and fender moulding clip. The creator reports that the imperfect reproduction holds tightly. Listed numbers 51131953927 and 51131965105 identify parent moulding assemblies, so no OEM number is assigned.

Replacement release handle for E30 Touring luggage-compartment side covers, physically installed and reported working with the original bent linkage rods. Verify both latches release and re-engage.

Replacement interior door-handle trim bezel for BMW E30, E24, E28 and E23, physically printed and fitted. BMWFans confirms cover 51211876043. Print in a UV- and cabin-heat-resistant material.

Two-piece conversion for the factory 1992–1999 E36 cupholder module, flattening and widening the support for modern cans and cups. The creator used the installed insert and documents 318i, 325i, 328i and M3 fitment. Use cabin-heat-resistant material and confirm the module still clips securely.

Left and right adapters for installing standard 5.25-inch rear speakers in the BMW E36 318ti Compact without cutting the original housings. The source shows the printed adapters, speaker assembly and installed housings. Verify speaker depth, wiring clearance and screw retention.

Three-gauge panel for the E36 sunglasses cubby, physically installed after widening the side clips by 2 mm. The uploaded orientation is for RHD; the creator directs LHD cars to mirror the model. Cutting the original cubby is required, so dry-fit the panel and preserve OBC and switch clearance.

Adapter for a standard 100 mm rear ceiling speaker in a 1998 E36 318i Touring. The source physically shows the printed ring, speaker and installed assembly. Confirm cone, magnet, wiring and headliner clearance before fastening.

Replacement push rivet for the 16 mm rear carpet holes in BMW E36 luggage compartments. The creator shows the finished print installed in carpet. Print in a tough material, test removal on one location, and do not force it into a smaller opening.

Small repair cap for a damaged front-door tweeter grille on a BMW E36 325i. The source photo shows the original damage and repaired physical cover. Verify the cap cannot contact the speaker cone or loosen into the door.

Eight left/right repair rails for broken BMW E36 Coupe and M3 Coupe door-panel attachment areas. The source documents the physical repair and installed door panel. Bond and clamp each section on the correct side, allow full cure, and verify window and latch clearance.

Replacement centre-vent insert measured from a BMW E36 323ti Compact and physically installed with a 52 mm gauge. It sacrifices vent airflow at that position; use cabin-heat-resistant material and verify gauge, wiring and dashboard clearance.

Press-fit E36 centre-console storage tray with separate coin and small-item areas, physically shown installed between the seats. Confirm it does not obstruct the handbrake, seat-belt buckles or seat travel.

Replacement interior door-trim clip traced from the original and modified for strength. The source physically compares the printed clip with the original. Test one clip for panel alignment and removal before replacing the full set.

Grooved replacement hook for the E36 Compact parcel-shelf cord, refined from the original model and physically compared with the stock hook. Print in a tough material and verify the cord releases without cracking the shelf.

Fourth-iteration replacement for the small slider-rail clip used in creator-listed E36, E39, E46 and E53 sunroofs. The source shows the physical print and a working demonstration. Use heat-resistant material and verify full sunroof travel, anti-pinch operation and water sealing before driving.

Left/right parcel-shelf support pin for BMW E36 Compact and E46 Compact, physically installed by the creator. BMWFans confirms the exact right support as 51468146708. Use a tough material and verify shelf engagement without overloading the side trim.

Multi-part repair set for BMW E36 passenger air-vent knobs, arms, plugs, lever, washer and connectors. The creator physically assembled and installed the revised parts. Select the matching left/right pieces and verify every louvre moves freely without binding.

Replacement holder for the BMW E36 engine-bay inspection lamp, physically printed by the creator. Use ABS, nylon or another engine-bay-rated material, secure the lamp wiring away from heat and moving components, and verify the lamp cannot detach.

67 mm cupholder and 54 mm reducer for the square opening ahead of the armrest in an E36 Compact. The source shows both sizes physically installed with 250 ml and 500 ml cans. Verify handbrake, shifter and armrest clearance before use.

Three glue-in repair bases for the different upper, middle and lower clip positions on BMW E36 A-pillar trim. The source physically shows the damaged trim and provides position-specific geometry. Mark each original location and verify the trim remains secure around any curtain-free wiring or seals.

Replacement spacer for the front drink recess in the BMW E36 factory centre-console cupholder, physically shown installed. The creator lists accessory number 82111469119, but it was not independently resolved to this printed subcomponent and is intentionally omitted.

Replacement inner translucent rocker for the BMW E36 power-window switch, physically compared with the original switch. The listed 61318365300 identifies the complete switch assembly, not this printed insert, so no OEM number is assigned. Use heat-resistant translucent material and verify return, illumination and anti-pinch operation.

Replacement sunroof-motor cover for BMW E36 Coupe, with separate switch-cutout and plain versions plus the source 3MF. The source shows a finished print and physical installation. Use cabin-heat-resistant material and verify switch, motor, headliner and retaining-clip clearance.

Two-gauge replacement for the BMW E36 centre vent. Only the physically printed and installed double-52 mm variant is retained from the source; its other untested variants are excluded. Confirm gauge depth, wiring, visibility and remaining demist airflow.

Two-file AEM-style and generic 52 mm gauge mount for the BMW E36 driver-side vent, physically installed and photographed. It preserves the centre vent but replaces airflow at this position. Verify gauge depth, wiring, sightline and steering clearance.

Replacement left/right lower clip-holder geometry for BMW E36 Compact door panels, supplied because the holders were available only with complete discontinued door cards. The source shows physical prints. Match the original position, bond securely and verify window and latch clearance.

I lost my cap some time ago and I found one here, but not for my model and not in design I wanted. Therefore I did model for my car. It is tested in e46 convertible, but probably will fit coupe and maybe also other models. Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

If you don't use the flashlight in your e46 BMW glovebox, here is a nice USB port adaptor that will plug right into the dash and give you two switched ports! I removed the center of the flashlight receptacle with a screwdriver and removed the pins, which are reused in the new adapter. Print both pieces, then wire two of these buck converters with 18AWG wire. There is not a lot of space, so you need to be delicate. Pin closest the the edge is negative. Solder the lead wires to the pins before inserting from the bottom - be careful not to insert too far. Push the assembled converter into the receptacle, push the female connector housing onto the back, plug in the wire from the car and re-inser Fuse and insulate any added wiring correctly, secure it from chafe and confirm the circuit remains serviceable.

I recently got a new (used) BMW E46 and noticed the panels that run along the top of the door had been damaged by the previous owner. Took out one of the not damaged clips and remade it in Fusion 360, then printed a handful to replace on all the doors. Worked a charm! Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

BMW E46 dash trim mounting clip. Part number: 51458266814 - Insert Rot. Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

These are speaker adapter mounts for BMW E46 front doors. There is a mount for both the tweeter and woofer. The mounts are designed for a JL Audio C3-525 component set but I have included generic .stp files for the mounts to adapt the design for your speakers. The woofers are screwed into the printed adapter rings and then the factory mounting screws are used to fix them to the door card. The tweeters clip into the mount with a twist and are held with integrated springs. The tweeter mounts also re-use the factory screws to hold them to the door cards. Left and right are exactly the same and there is no need to mirror the mounts. These fit perfectly and I have had no issues after a month of i Fuse and insulate any added wiring correctly, secure it from chafe and confirm the circuit remains serviceable.

ist denk ich selbsterklärend, habe ihn mehrfach verbaut und er hält. Beim montieren ausrichten, damit er beim Ansetzen nicht bricht ;) Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

Repair bushing for the E46 and E53 window regulator, physically assembled and load-tested by the creator with an M6 thread. The creator warns that ordinary PLA failed in summer heat. Use heat-resistant automotive material, dry-fit before fastening, and verify glass, latch, wiring and trim clearance through full operation.

When I bought a E46 Compact it had broken rear shelf retaining clip. So whenever I opened the trunk the shelf would hang randomly in the air. Also it made closing the trunk hard, as it jammed between the trunk lid and the body of the car. So I decided to make a model of the broken shelf clip, that came with the car. It may need some sanding or filing to achieve a better fitment in the shelf steel tube. Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

Mine got lost, so I decided to make one! Print in PETG or other heat resistant filament. BMW (E46 3 Series, E83 X3) Battery Positive Terminal Base B + - Cover Cap (61138371011) Fuse and insulate any added wiring correctly, secure it from chafe and confirm the circuit remains serviceable.

A Friend of mine lost one of the adjustment Knobs of his E46 Cabrio, you can buy it for the bargain of 180€, after 1h of modeling in Fusion360 the cost sank to 50ct a piece Confirm seat movement, belt access and occupant clearance before use.

[*TIRES SQUEAL AROUND TIGHT BEND* "Ugh, there goes my polar pop!"] Don't let this be you! This E46 cup holder expander will give your large size beverage a more comfortable place to rest. I have designed this one using Fusion360's shape optimization (hence the crazy design). Feel free to edit as you please and make the cup holder fit your favorite oversize mug or water bottle using the attached Fusion360 File. Enjoy. Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

The carpeted panel on the interior of the E46 touring hatch is tricky to remove, and often the retaining clips are broken. I have created these two clips which can be epoxied in place to return normal function. In order to use them, completely cut the broken part of the clips out as shown in the photo then, use an epoxy like JB Weld liberally - the holes provide a mechanical bond for the epoxy. Note there are a right and a left. I did not create the center clip. Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

Replacement upper retaining clip for the rear front-seat back panel, modeled from the surviving seat-panel clip profile and physically compared with the panel. The nearby V5BB Brombeer catalog number identifies the complete parent panel and is intentionally omitted. Confirm seat movement, belt access and occupant clearance before use.

Cupholder insert for the rear armrest of BMW E46. The backing is inserted under the leather. Use the backing to mark the location for your cuts. A single slit in the center "web" is also needed to get the backing into the armrest. Carve out the foam as needed to clear the cupholder. Insert the backing, insert the cupholder and use 6 wood screws to hold them together. The screws I used have 4mm outer thread. Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

Greetings. At the moment, the model has already been strengthened and differs from the photo! There was a lot of window play in my E46. the glass rose heavily and crookedly. after disassembling the power window, it became clear that there was strong wear and tear and a large backlash. The brace does not come as a separate spare part, and you cannot buy an official one separately. My model is not perfect, it is robust, reinforced. Copes with its function. Window regulator carriage, right door, farthest from the motor v7. home plate (m) the following model, using the native metal plate in the link Dry-fit before fastening and verify glass, latch, wiring and trim clearance through full operation.

i bought RHD mirrors to my LHD e46 non-M Coupe and I created this raisers in order to get a better view angles (close to regular mirrors). This can be use to rise the angle of either side of the mirror and can be used in both mirrors. So with this you can "transform" RHD to LHD and viceversa. Dry-fit before fastening and verify glass, latch, wiring and trim clearance through full operation.

Hello this is an alternative sliding cover for rear console ashtray in an e46. Both my brothers and my e46 were missing the covers and its a bit of a pricey piece to replace for what it is. I printed in PLA+ with layer lines running against the slats to prevent breakage. Id recommend something like PETG but so far so good in our cars! Included is a 10min test piece file to check fitment and flexibility of your material. You can bend bottom of the cover gently to the curve of the slot before inserting first time to make it go in smooth. If the top of the cover with handle isnt flush when first installed you can bend it up a bit until its flat. I did what I had to do make it work with PLA+ so Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

Print standing vertically, Coat with a clear Just glue on your trim and push it on Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

Coloring the m logo will make it way better! Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

5mm Cable Holder Headlight Bracket Wiring Harness Trim Clip cable clips used to hold the headlight wiring under the hood, redesigned to be easy printable OEM: 61138350827 Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

These clips can be glued in your oval mirror housing of a BMW E39 M5 or E46 M3 to repair the broken ones. Use "crazyglue" and line the clips up with the missing tabs in the housing. See photos for reference. Dry-fit before fastening and verify glass, latch, wiring and trim clearance through full operation.

replacement interior hood latch, original often breaks this version is way stronger than the original Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

My dog rides shotgun and would always step on the hazard button when getting in and out, or when I left him in the car. I made this button cover to prevent paws from being able to activate the buttons, but still allow a finger to hit them easily. This is a friction fit in my car and doesn't move around at all. I sanded the top surface in the main picture. source openscad file is attached. Print Settings Printer Brand: PowerSpec Printer: PowerSpec 3D Pro Rafts: No Supports: No Resolution: 0.2mm layer height Infill: 20% Notes: printed upside down Post-Printing I sanded the top surface to make it a matte finish so it doesn't stick out in the car. Category: Automotive Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

This is a remixed version of the original thing posted here on Thingiverse, which is a shift boot bracket for the BMW E46 3 Series. It has better strength as with the added fillets and the clips are thickened as well as enlarged for better fitment. It will fit both RHD and LHD BMW E46 and will provide tight fitment. If you are planning to install with thick Alcantara leather boot, then it will be wise to scale it down a bit to 96-97% scale but if you are just planning to use faux leather boot, then at 100% scale it will be just fine. Use custom support blockers to increase the infill density of the clips to 99% for added strength. Print it in ABS or PETG because PLA will definitely deform du Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

Isofix cover for BMW E46 I was missing one of the isofix covers so I modeled and printed this one. It's not a perfect copy since I added a bit of thickness in some parts to make it stronger. You can see in one of the images the differences between the original and the 3d printed part. For this one the ABS filament is required since the PETG & PLA are not rigid enough. Added a magnetic version, magnet can be glued in place, 20 x 10 x 3 mm magnet size. This alleviates the need to print the part in ABS for strength. Print Settings Printer: TwoTrees Bluer Rafts: Doesn't Matter Supports: Yes Resolution: 0.2 Filament: Generic ABS Black Notes: Category: Automotive Confirm seat movement, belt access and occupant clearance before use.

Front-door adapter for installing a 165 mm speaker in the E46 Compact, whose factory speaker differs from other E46 bodies. The creator documents the original door, factory speaker, printed adapter and finished installation. Dry-fit before fastening and verify glass, wiring, cone and door-trim clearance through full window travel.

Print a cheap replacement for OEM E46 sun visor clips. I recommend printing at 100% infill to prevent splitting at layers when installed. I had good success with a 98A TPU filament at 100% infill with supports on. Just give extra support spacing with TPU and use a torch after to lightly clean up any strings. Wouldn't recommend PLA due to the high temperature that the inside of vehicles can see during the summer heat. Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

Five-piece adapter set for 165 mm midrange speakers and 44 mm tweeters in Euro-spec E46 Coupe and Convertible doors without factory Hi-Fi or Harman Kardon. The creator documents the original mounts, printed adapters, driver assembly and installed sound-deadened doors. Verify speaker, wiring, window and door-trim clearance before fastening.

This bracket allows to mount the Pioneer GM-D1004 amp in place of the factory amp in the trunk. I used PETG and it works fine. Put some automotive Tesa tape on the metal ears before sliding the bracket to dampen vibrations. If You are missing a mounting screw or nut here are the codes: 07119902932, 61131372033. Fuse and insulate any added wiring correctly, secure it from chafe and confirm the circuit remains serviceable.

Front-door reduction adapter physically used in an E46 325Ci Coupe to install a 5.25-inch Kicker speaker in the factory 6.5-inch position. The source shows the printed ring, driver assembly and door fitment. Use sealing foam as documented and verify cone, magnet, wiring, window and door-trim clearance before fastening.

Do NOT print it in PLA, it will deform/melt. Printed with supports. Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

Filament: ASA Supports: Yes (As Applicable) Infill: Minimum 15% Brim: Yes (As Applicable) Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

These are brackets to mount an oddments tray (part no 51478230573) that is used in sedans instead of CD changer in the trunk. The brackets allow mounting the caddy in touring as well. Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

We did 6 different version to get it in the angle that it faces the driver. We had a tight fit so it did not need any mounting to the dash, but maybe some glue or other adhesive wouldn't hurt. Printed flat down on the surface, with ABS+ to resist the summer heat in the car. Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

Replacement ashtray insert with space for a switch that disconnects the E46 always-live cigarette-lighter outlet. The creator documents the physical insert, wiring and installed switch. Use an automotive rated switch and protected wiring, retain correct fuse protection, insulate every terminal and confirm the ashtray closes freely.

E46 4" Speaker Adapter for Coupe/M3 This adapter screws directly into the original speaker pod. The threads are slightly loose, allowing space for Teflon tape. I applied Teflon tape to ensure a secure fit and prevent the speaker from vibrating loose over time. The speaker is fastened with M4 screws, with a little dab of loctite on them. Dry-fit before fastening and verify glass, latch, wiring and trim clearance through full operation.

Inserts into the stock E46 ashtray, should be friction fit. I included all of my files, with the following features: .stl with the holder cutouts intended for my own use, Hörmann Garage Door Opener, a ISO/IEC 7810 ID1 cutout and a generic one to use the remaining space .step without cutouts for your own modifications .f3d so you can look at my bad modelling skills and also make your own modifications I would recommend to print this in ABS, PETG may be fine but PLA will 100% shrink if your car heats up. Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

This is a custom USB holder designed to replace the button blanking strip on a BMW E46 dashboard – the one next to the ASC/DSC button. It’s a remix of another model, but with serious upgrades: ✅ Now with 3 Holes : I added a third port so you can mount a standard car charger PCB . Just remove the plastic casing and drop in the board. Works perfectly with generic AliExpress/Amazon 12V USB chargers. 🔩 Rear Clamp with M3 Bolts : The back has a clamp system for a solid hold using M3 bolts and heat-set inserts (not required, but highly recommended). 📐 Includes STEP File : I reverse-engineered the original STL in Fusion 360 and included a clean STEP file for anyone who wants to customize it further Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

Print with a filament that can survive the temperatures in the car. I have added the step so you could add buttons or anything else if you want. Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

I created this repair wheel for the armrest, since it most often breaks or cracks in the joint, this wheel is installed and inserted in the place where the spring was originally. (and stick there) Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

Got tired of the Velcro pads failing constantly, forcing me to adjust the floor mats every damn time I got in the car. This is my solution. Printing: Small part, so go 100% infill @ .2 or smaller Button face down Organic supports on crossmember PETG pref Install: Remove existing Velcro pads. Align floor mats. Eyeball orientation and location of vertical slot through carpet. Large swiss army knife blade is more or less perfect height. Cut a vertical slit through the carpet into corresponding chassis slot. Pass clip through carpet, into retention slot, and use a nickle/quarter to lock the clip into place. vroom vroom. Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

This tray replaces the rubbery insert in the coin holder trim on the E46. Mine had begun to degrade, looking waxy and crumbling. I printed this from 85A TPU to replace it. Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

This adapter was used to mount a 25mm twweter of u-Dimension EL Comp 6 system into BMW E46 coupe. You need to print an aditional RH version of LH model provided below. Dry-fit before fastening and verify glass, latch, wiring and trim clearance through full operation.

Doorstep broken clip holder part replacement. Designed to have large surface area for glue to properly hold it. I have also designed the clip, check my other designs. Print with 5+ walls vertically oriented , and glue it on the bracket with 2 component glue for best results. Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

Made this few years back. Still intact till today. Drop a comment for feedbacks Printed in ASA 100% fill. ABS or others Enable "Detect Thin Wall" Use cabin-heat-resistant material, dry-fit the part and confirm secure retention and unobstructed operation.

The BMW E92 has under-seat air-con vents which are prone to getting small objects kicked down them by rear seat passengers. Worse, there a small gap between them through which coins and the like can end up under the carpet where they then rattle annoyingly. Getting them out is a real pain an requires the seat, and possibly the speaker under it, to be removed. These simple grills clip over the vents preventing small objects going where they shouldn't. Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed operation.

This is the cap for the positive battery terminal for a BMW E90. It should fit just about any BMW. Use automotive-rated wiring and connectors, retain fuse protection, insulate every terminal and verify unobstructed operation.

When I bought my e91 it had no front console cigarette lighter which meant I had to use an after market accessory plugged into the armrest socket. The unit was then wedged between the console and the passenger seat. Less than ideal. This plate fits in the ashtray hole and has a cut-out to accept an after market twin socket adapter which can be commonly found online or in value stores. I desinged this in sketchup and have included the SKP file in case anyone would like to remix it. Happy Printing Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed operation.

The cup holders in my 325i are small and work with anything bigger then a 12oz can. I designed this cup holder fit large insulated tumblers like the Yeti. The top 2 pieces need to be glued together. Gorilla glue works well, but any plastic glue should work. I used a hot glue gun to secure the base to the center console of the car. The hot glue works well and can be removed without any damage to your car. Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed operation.

The is a model of a BMW E90 plastic nut. These nuts are used in the undertray, splashguard and several other places in the vehicle. The nut itself is unthreaded since it is screwed onto a thread cutting fastener. The inner diameter of the nut is 4.25mm. The nut fits a 10mm wrench. Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed operation.

Shift knob designed for e90 but may fit others. Clips on and does not rotate (careful of breakage if you try to twist it!) Fits fine, but is a bit light. Would be a nice print in transparent colors. Difficult to remove without breaking the teeth! (the knob teeth not yours) Please share your makes :) Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed operation.

Seat belt hook attachment for BMW E92. Simply attach with a high quality double sided tape. Confirm normal seat, belt and presenter movement and keep the printed part outside the restraint load path.

OBD2-Cover for BMW e90/e91 Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed operation.

In my BMW E91 were the Air Vent Levers missing. The original replacements cost a fortune, so i designed some by myself. Print them with PETG or similar. I recommend to print the fork with hinge part. Use the Fork and the Lock File only if you want to print them separately. For the stripe you may want to change the color, so i made it one part for manual color change by a certain height and two parts for MMU printing. You should add a raft under the Leverpart for better bed adhesion on the very small parts lying on the bed. Print them in the provided orientation Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed operation.

Dies ist ein Dosenhalter, der für Red Bull Dosen designt wurde. Der Durchmesser der Öffnung für die Dose ist 55mm. Der Halter ist nur nutzbar, wenn kein iDrive vorhanden ist, da er dort platziert wird wo die Steuerungseinheit ist! Dauer: 12h 3 min Maße: 74.8 x 135.1 x 72.4 mm Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed operation.

So I was looking for a fitting cupholder for my BMW E90 tray and couldn't find one which wasn't too big. This one fits to your BMW E90 without the big navi and without the iDrive knob. I made 3 versions which can fit 250ml, 330ml or 500ml cans (Germany/EU). With the big one, the walls might get too thin, read below. It fits very good to the tray, I use it everyday. This was designed to be printed with PLA, if you use ABS you might upscale it. Also, you can print it on the flat surface with my tag without supports. If you like the design, leave a tip :) *** Update 27.06.20 Someone requested a wider hole (currently 57mm) for norwegian 500ml cans. Uploaded another version with 66mm. Walls get very thin and cut, NO guarantee for good results as I won't try it! *** Update 11.07.20 Was shopping a german/EU 330ml can and couldn't fit it. So I made the hole slightly wider (59mm) to fit these. Ha Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed operation.

Can be installed in preexisting holes, no drilling necessary. BOM: 2 x M4x10 screws 1 x M4x50 screw 3 x M4 nuts Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed operation.

REPLACEMENT TRAY FOR USELESS PHONE CADDY watch this to learn how to remove that useless thing NOT MINE VIDEO ALL THE CREDIT TO THAT GENTLEMAN And then replace it wit the tray enjoy Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed operation.

This is a nice update for us with older E90 BMW's This will allow you to mount a universal Inbay wireless charger. This seems to work well and looks like a factory addition. It will take place of the front pocket in the console or the ashtray if it was equipped. This bracket will mount directly inplace of the old insert. Powering up the device: I did not have the ashtray so I was able to wire this into the power of the usb in th back of the console. you can access this easily by removing the rear vent panel. you can also pull out the plastic rear vent tubing with a little force to more room. You will tap into the Brown/ Ground and the Red/ +12V going to the usb in the rear console. LED Light: As an option I have added some holes for the LED light on the side of the charger. you will need to source a thin fiber optic cable and use the included plastic insert to fit the bigger hole. you wi Use automotive-rated wiring and connectors, retain fuse protection, insulate every terminal and verify unobstructed operation.

Adapter for side led blinker - bmw e90 Use automotive-rated wiring and connectors, retain fuse protection, insulate every terminal and verify unobstructed operation.

This is a cover to replace the 12v point in the boot/trunk of an E91 ( check for other models similar) with a blank plate. For fitment insert widest plastic tap to top and tap/hammer upwards. Then support the plastic of car from behind and push/hammer in. Push down to seat and stop it falling out. Cleaning up of carpet and plastic edge of hole may be required. Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed operation.

The dashboard panel around the start button in my e92 began falling off due to a failed clip. I left it like this for quite awhile then the passenger door wood panel also fell off so I decided to design both clips to replace the broken ones as they cost more money than im willing to pay for original and aem ones dont last one use. I printed them with support on their sides so the opening is going up and down as this doesnt rely on layer adhesion for strength. "dash clip 1" is the dash clip "clip 3" is the door clip Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed operation.

This connector moves all the louvers in the vent together. Originally is made of metal and super thin. Printed with 100% infill Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed operation.

Compré unos proyectores para las puertas del E90 y estas no traen instalación ya que no cogí el pack de iluminación. He subido dos modelos que se ajustan al plafón de luces. En mi caso voy a utilizar el más grande. Luego he utilizado un peine de puentes de electrónica para utilizar la parte hembra que es donde conecta el plafón y la parte del macho he soldado positivo y negativo. He puesto termoretractil para que quede más seguro. Subo un sketchup por si se quiere modificar Use automotive-rated wiring and connectors, retain fuse protection, insulate every terminal and verify unobstructed operation.

Adjusted the model for it to fit perfectly without cutting imporant parts of the car. Only thing to remove is the bracket where the electrical conntection for the ashtray connects to. Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed operation.

This replacement clip is designed for the BMW E9x M3 (E90, E92, E93) center console shifter boot. If your shifter boot keeps detaching or won’t stay secured, this clip is the perfect solution. Installation: This clip must be glued in place where the original clip was broken off. Once installed, it restores a snug fit and keeps your shifter boot securely attached. Features: Perfect Fit: Precisely modeled to match OEM dimensions for a secure hold. Durable Material: Recommended to print in PETG or ASA for strength, heat resistance, and longevity. Easy Repair: Simply glue it where the original clip was — no modifications needed. OEM-Style Design: Matches original fit and function without compromising appearance. Compatibility: BMW E90 M3 BMW E92 M3 BMW E93 M3 Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed operation.

A friend of mine has an E90 and lost the clips that hold the (rear) window shades in, he was looking everywhere for them and couldn't find any at a reasonable price so I had a crack and modelling and printing them for him. They're pretty close to the original design and have similar properties when printed with PETG. I thought I'd share the model in case anyone else is also struggling to find them. If you encounter any issues let me know and I'll tweak the design for you. I'm unsure of their BMW part number, but the sun shade is 51462359741 . Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed operation.

I created this for my 2011 E91, but it may fit others. Just pull the other parts out of the vent and snap this one on. Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed operation.

I added a 29mm cigarette lighter hole and a bmw logo on top of Fix3D:s model. You should probably use the original model's slicer settings. I used mostly default settings and the print could have come out better:) The bottoms of the holes are pretty thin and the other one broke on me while removing from the print bed, so I printed some BMW coasters with a diameter of 65mm and put them in the holes to hold the drinks. Printed in PETG basic Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed operation.

This model replaces the chrome cap of the BMW coupe E92 extender arm with a hook that grabs the seatbelt successfully much more often than the original design. Designed to be a near perfect fit with the OEM shape. I recommend printing in ASA or ABS for the high temperatures in a car. The OEM piece easily comes off with a pry tool, then you can attach the 3d printed models with a strong double sided adhesive ( Confirm normal seat, belt and presenter movement and keep the printed part outside the restraint load path.

Replacement storage tray for the center-console cavity left after removing the factory phone cradle in a 2013 BMW 320. Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed vehicle operation.

Adapter for installing a universal 100 mm speaker in the original BMW F30/F31 speaker location. Use cabin-rated material, isolate wiring and connectors, and verify secure fit and unobstructed speaker operation.

Cup-holder insert that steadies slim beverage cans and raises a small fragrance tin for easier removal in BMW F3x interiors. Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed vehicle operation.

Small removable coin cup printed for the recessed BMW F30/F31 center cup holder. Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed vehicle operation.

F30 cup-holder organizer for a garage-door remote, coin, keys and other small cabin items. Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed vehicle operation.

Small storage bin fitted beside the handbrake lever in a BMW F30 328i. Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed vehicle operation.

Two-piece open- or closed-loop umbrella mount demonstrated on the inside of an F31 Touring boot lid. Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed vehicle operation.

4.5 mm depth adapter for installing a BLAM BM200W 200 mm subwoofer in the original HiFi enclosure of a BMW F34 3 Series Gran Turismo. Use cabin-rated material, isolate wiring and connectors, and verify secure fit and unobstructed speaker operation.

Parametric insert demonstrated in the sliding-cover cup holder used by BMW F30/F31 and F32/F36 LCI interiors. Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed vehicle operation.

Clip-on shopping-bag hook demonstrated on the factory rear parcel-shelf cover of BMW F31 and G31 Touring models. Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed vehicle operation.

Two-piece fold-down bag hook designed and physically demonstrated in the trunk of a BMW G20 3 Series. Install with an M6 nut, a 25–40 mm M6 socket-head bolt and a temporary nut-retaining aid as described by the creator. Use cabin-heat-resistant material, confirm the mounting point is structurally suitable, keep the load light and verify the hook and cargo cannot interfere with the trunk lid, wiring or emergency equipment.

Console insert for BMW G20 and G21 3 Series cars without the factory wireless-charging trim, physically shown installed after removal of the original rubber mat. It accepts an Apple MagSafe puck, a 90-degree USB-C adapter and a slim 12 V USB-C adapter. Use cabin-heat-resistant material, secure and protect the cable, preserve access to controls and cup holders, and confirm the phone remains retained without obstructing driving controls.

Left and right replacement brackets for retaining the metal badge inserts in BMW G20/G21-family all-weather floor mats. The creator reports iterative fit testing and explains that the metal tabs pass through the bracket openings before the bracket is press-slid into place. Use PETG or ABS, fit only to the mat badge area, and verify the mat remains fully anchored with no loose piece or raised edge near any pedal before driving.

Clip-on key-fob holder designed and physically demonstrated in the cup-holder trim of a BMW F33 4 Series Convertible. The creator confirms the fit in his F33; no fitment to visually similar 1–4 Series interiors is inferred. Use cabin-heat-resistant material, dry-fit the clip, and verify that it cannot obstruct the controls, selector, handbrake or cup-holder use.

Replacement clip and glue-in double-stud repair for broken F33 Convertible roof-frame moulding retainers, designed on and physically demonstrated with a 435i F33. The BMW clip file corresponds to superseded 51 76 7 162 587, now 51 76 5 A71 150; the custom glue-in double stud is not separately serviced and no moulding assembly number is assigned. Use heat- and UV-resistant material plus high-strength compatible adhesive, follow the creator's hook orientation, and verify full roof travel, strip retention, drainage and sealing before driving.

Three-piece detachable Qi charging stand physically demonstrated in the center cup holder of a BMW F32. It uses a user-supplied silicone Qi charging pad and routes its USB cable through the cup base; other chassis fitments are not inferred. Use cabin-heat-resistant material, electrically sound charging hardware and protected cable routing, and verify secure retention, cooling and unobstructed controls before driving.

Upper and lower storage trays with cutting templates for the F32/F33 center-console cavity after removal of the original phone cradle. The creator physically demonstrates both the shallow installation and the optional deeper cut-out; the cutting templates are retained as functional parts of the set. Use cabin-heat-resistant material, protect wiring before any cutting, deburr the opening, and verify secure fit and unobstructed console operation.

Vent support for a Quad Lock phone interface, physically demonstrated on the right-hand-drive driver's-side center vent shared by the creator-listed BMW F30, F31 and F32. Fitment is limited to those bodies and RHD placement; F33/F36 and LHD fitment are not inferred. Use cabin-heat-resistant material, tighten without damaging the vent, and verify full vent, display, control and sightline clearance before driving.

Replacement center retaining clip for the sun visor of a BMW E12 520. The creator physically fitted the part and recommends PETG, ASA, ABS or another cabin-heat-resistant material; PLA can deform in summer. BMW catalogs identify the equivalent ivory holder as 51161870863, superseding 51161820684; the photographed black print is a user-selected reproduction color, not an OEM color claim. Production date and trim variants can differ, so compare the two-hole base and visor-rod diameter before fitting.

Spacer and washer for fitting an upgraded 4×6-inch front speaker in a BMW E28 while retaining the original speaker cover. The creator confirms that the hood-release lever still clears the speaker and specifies longer #8×1.25-inch oval-head screws with #6-32 speed nuts. Check speaker depth and fastener clearance before final assembly.

Front and rear spacer geometry with locating rod for installing a Musway ME462 coaxial speaker in a BMW E28 sedan. The creator reports that the adapter set fits perfectly. This is specific to the stated speaker footprint; compare the mounting pattern, depth and trim clearance before printing for another driver.

Replacement rotating knob/head for the manual sunroof crank of a BMW E28. The creator printed the part in PLA; PETG or ABS is preferable for a hot cabin. BMW catalogs supply the knob only with the complete crank handle, so no parent-assembly number is assigned. Confirm crank-pin diameter, trim color and production-date variation before fitting.

Replacement manual shifter-boot retaining frame for BMW E28 and E24 interiors. The creator measured an E28, fitted the design in the car and recommends PETG because PLA prototypes softened in cabin heat. The test car has a short shifter; correct worn or misadjusted linkage rather than relying on this frame to solve reverse-gear interference.

Two alternative lower hook-holder geometries for the BMW accessory rear roller sunshade: an original-dimension version and a tighter-fit version tested in an early 1985 car. BMW references include discontinued white accessory hook 82129413177 and anthracite holder 51461905393, which supersedes 51461887130. E28/E30 body, production date, color and accessory installation vary; compare the no-screw-hole mounting style before use.

Replacement roof hook for the accessory rear roller sunshade used on BMW E28, E30 and E34. It was reproduced from an original part and physically installed. BMW accessory number 82129413178 identifies the discontinued black two-piece roof-hook set; 82129413177 is the different white lower-hook style. Confirm headliner mounting, accessory configuration and color before fitting.

Reinforcement bracket that replaces the flat nut at an E28 glovebox mounting point. Three prints and one M4 nut per bracket position are required to reinforce all mounting points. The creator used ABS+ and shows the parts fitted to the glovebox panel. Check screw length and ensure the bracket does not distort the glovebox shell.

Drop-in cup holder for the BMW E28 center console, shown physically installed beside the shifter. The source is dedicated to this chassis and released to the public domain. Confirm console shape, shifter travel and access to adjacent controls before use; finish or pad contact surfaces as needed to prevent trim abrasion.

Left/right interior mounting pod for adding tweeters in a BMW E28. The photographed print is installed in the car; the opening is intentionally generic, so select a tweeter that fits or design a separate driver adapter. Confirm mirror-image orientation, trim contour, sight lines and airbag-free mounting location before drilling or fastening.

Four clip-in replacement gear-knob shapes for the BMW E34 and the creator-listed classic BMW chassis. The design was developed around the common BMW latching stem and includes an installed physical example. Confirm the lever's clip profile and preserve full shift travel before driving; the grouped API fitments reproduce only chassis families explicitly listed by the creator.

Two-piece cup holder physically fitted in the center-console tray of a 1990 E34 525i. Its foot resists tipping, the lower bore is 64 mm and the upper opening is 82 mm with a mug-handle slot. Adjust the press fit in the actual console before bonding the halves and check shifter and handbrake clearance.

Replacement clip copied from the surviving original on an E34 climate-control actuator. It snaps into the actuator while the flap-control arm clips into its center. Print in a heat-tolerant engineering material and compare both snap features with an intact original before cycling the HVAC system.

Two-piece repair bushing for the riveted rear window-regulator slider used on BMW E32, E34 and E36. The creator built it for a personal repair so the original rivet can remain in place, and retained the two halves with friction plus an O-ring. Inspect the regulator, lubricate the guide correctly and confirm smooth glass travel before refitting trim.

Replacement lower glovebox hinge reproduced from the intact hinge in an E34 and physically installed. It substitutes an M6 screw and nut for the original locking lever; two hinges are used per glovebox. Tighten only enough for free movement and confirm the door latches without stressing the glovebox shell.

Center-console housing built and installed in an E34 for three 52 mm auxiliary gauges, with an on/off switch and two USB sockets. The source also identifies E32 fitment and supplies a wiring diagram. Treat it as a housing only: use fused automotive wiring, preserve control clearance and verify console dimensions before trimming or upholstery.

Replacement medium-gray lock clip for the E34 luggage-compartment carpet, reproduced against the original shown by the creator. BMW catalogs identify the exact component as 51478102980, produced from April 1988 across E34 sedan applications with LHD/RHD and manual/automatic variants. Match carpet and trim hole condition before use.

Replacement push clip for attaching the lower interior side panel in a BMW E34. The source is chassis-specific and supplies the mating clip geometry. Compare stem diameter and panel thickness with the surviving fastener and use a flexible, heat-tolerant material so removal does not damage the trim.

Flexible replacement strip for the E34 automatic selector gate, with a 16 mm opening for the shifter stalk. The creator specifies TPU at roughly 50% infill. Verify selector travel through every position and ensure the strip cannot bind, bunch up or interfere with the shift-lock mechanism.

Three replacement gears for the mechanical odometer in the early E34 LOW instrument cluster. The creator limits the set to start-of-production through September 1990 clusters used in 518i, 520i, 524td, 525td and 525tds variants. Compare the cluster face and tooth counts before disassembly; later or HIGH clusters are not represented.

Dual cup holder installed in the center-console tray of the creator's classic BMW and explicitly released for E32/E34 preservation. It is a distinct two-container layout from the selected single-cup design. Verify tray width, handbrake and selector clearance, and secure the insert so it cannot move under braking.

Replacement black blanking cover for an unused dashboard switch opening on BMW E32, E34, E36 and Z3. The source gives interchange number 51161963979, which BMWFans confirms as black cover 1963979 produced from April 1987; the alternate 51161963987 could not be catalog-confirmed and is intentionally omitted. Check color, opening and switch-bank configuration.

Replacement retaining clip for the automatic climate-control unit in an E34 M5. The creator physically installed the PETG print, sanded the nibs slightly and reports that it holds the unit. This differs from the separate HVAC actuator-arm clip; compare the installed clip and remove only minimal material for a secure snap fit.

Replacement 158.2×191.0×12.8 mm headliner cover for the E34 sunroof-control area, supplied as STL and STEP and shown against the installed roof console. The creator recommends ABS or PETG at full infill. Verify sunroof switch, interior-light and headliner opening configuration because option and trim variations are not interchangeable.

Battery-retaining spacer reproduced from BMW component 61211350825 for E30, E34, E39 and E46. BMWFans identifies it as spacer 1350825 and confirms those chassis among broader BMW usage. Match battery size, tray slot and hold-down engagement, and do not use it to compensate for an incorrect battery or damaged clamp.

Update: Few of those broke using PLA 0.8 width, infill 10-25%. I suggest you print with 3 layers width (or more?). I will do a redesign to fix the weak point from printing prescriptive. This is my design for BMW floor mat holder (E36 E46 E38 E39) . Top part fits nice and works like a charm. I would say it even holds better than original one. As for the washer (bottom one) I haven't got it in real life so I've designed whatever I thought was suitable. Tested with PLA. Lay it down to print upside down. For now tests are held only in V1 version. Version 1: - Design created. Printed with CURA supports Version 2: - Added supports included in file. Gap is 0.15mm - Redesign of top part "head" - Added washer BMW part number (exemplary) 51478116564 51478183027 51478183028 51478183029 51471881521 Only the creator-tested V1 fastener is retained; the untested V2 washer and supported variant are excluded. Verify dimensions against the original part and confirm full operation before regular use.

This is a rear window sunshade hook for BMW E39. Verify dimensions against the original part and confirm full operation before regular use.

Very basic blanking plate for the E39 BMW 5 Series rear cup holder. The rear cup holder in my E39 BMW has never closed properly and never clipped in properly and EVERY time someone sits in the rear seat it gets kicked. Odd design by BMW as the cup holder keeps the rear air vents in place so when the cup holder falls out so does the air vent. Printed in blue for prototyping! Second design with holes for 2 USB chargers or cigarette lighter sockets. I used the ones with rubber covers from banggood. The clips are very crude. They need a better design as this panel does not like being removed. Verify dimensions against the original part and confirm full operation before regular use.

My BMW E39 5 Series was missing the selection switch for the power mirror. (I don't know how the previous owner could rip that thing off...) Here you can find a custom-made replacement switch. Just push it into its place. If you have any ideas for improvement, please feel free to contact me. Verify dimensions against the original part and confirm full operation before regular use.

My BMW E39 wagon (touring) was missing the plastic clips at both sides of the tailgate. These clips hold the plastic side covers in place. Since the original spare parts (BMW part number: left: 51498217213, right:51498217214) are way too expensive, I have decided to print my own ones. The uploaded files contain the right side clips, but you can mirror them in Cura so that you also have the left side ones (see pictures). BMW catalog identifies the black left/right clips from 1996-09 for E39 Touring, including cataloged European/USA and LHD/RHD applications; mirror the supplied right-side model for the left. Verify dimensions against the original part and confirm full operation before regular use.

My BMW E39 was missing some fan grille parts for the rear seats. The CAD drawings have the exact same size as the original parts. So it just depends on how accurate your printer is (I had to sand down some areas). As you can see in the pictures you will also need a small piece of sheet metal that acts as a spring. Verify dimensions against the original part and confirm full operation before regular use.

Older German cars are notorious for having bad cup holder, the BMW E39's cup holders are some of the worst. Here is what's wrong with the front OEM cup holders: -They are flimsy and weak so cups tip over. -The bottoms are shallow so any cup with more than 2" of drink in it will tip over. -The centre console design tapers backward as it goes up so any long cups tip backward. -The cup holder are located in front of the climate controls, heated seats and parking sensor button, so you cannot access those buttons if there is a cup in the cup holder! -The climate control sensor is locate above the cup holder so hot drinks (e.g. in the winter) turn on the AC, and cold drinks (e.g. in the summer) turn on the heater! So it's not only the OEM design that's bad but also its location. In my design I solved both the design and location problems. I use this cup holder in my car (see image) and it works and looks great: No tipped over cups, no spills or burns, no tempering with the AC temperature, and no blocking of any controls! My cup holder design does not interfere with the stereophonic function of the transmission, so you still get to enjoy changing gears when you want to! Please note that t Creator limits fitment to 1997-2003 left-hand-drive E39 cars with automatic transmission. Verify dimensions against the original part and confirm full operation before regular use.

I designed it in a blender. Fits cars: BMW X5 E53, 1999-2007 BMW E39 series 5, 1995-2005 I printed it on cr-10 with .4 nozzle and .2 layer height Verify dimensions against the original part and confirm full operation before regular use.

Volume Button for BMW E39. Replaces original button with Part Number: 65828372163 Not for any BMW E39 - check the part number! BMW catalog lists button 65828372163 from 1995-09 across E39 Sedan/Touring and broad global LHD/RHD applications; confirm the radio face and knob number before printing. Verify dimensions against the original part and confirm full operation before regular use.

Clip zum anschrauben der oberen Seitenrollohalter im Türrahmen. Bei BMW leider nicht im ETK zu finden. Verify dimensions against the original part and confirm full operation before regular use.

This is for all the RHD E39 owners because I couldn't find any online except LHD so I designed a new one :D When printing flip the whole thing on its bottom so it prints properly. :D Btw the pictures got squashed by the site so to see a better image view the original image by clicking the fullscreen button at the top right and then click view original image. Creator identifies right-hand-drive fitment. Verify dimensions against the original part and confirm full operation before regular use.

Guten Taaag. Dem E39 Fahrer geht es ja seit langem auf den Geist keinen Schönen Cupholder zu haben. Nun, dem mache ich nun ein Ende :D Ich habe 2 Halterungen für einen Universalen T2/T3 Getränkehalter entworfen. Funktioniert mit allen Getränkegrößen vom McDonalds super, auch kleinere Getränke kippen nicht um. Max. PET Flaschen sind 0.5L Es MUSS in ABS oder PETG gedruckt werden, mit PLA schmilzt es im Auto im Sommer davon. Es müssen 2 Stück gedruckt werden. Nacharbeiten sind folgende: M4 Gewinde in die Löcher Schneiden, Schrauben bündig Ablängen dass nix heraussteht, Halter am Getränkehalter Anbringen und Fertig. Dem Halter liegen Original solche Blechdinger dabei, die sind jedoch alles andere als Stabil und Lutschen aus. Hier der Link zum Passenden Halter: Verify dimensions against the original part and confirm full operation before regular use.

This thing was made with Tinkercad. Work In progress. For BMW Center Console Storage Coin Tray replacement. Verify dimensions against the original part and confirm full operation before regular use.

Clip for sunblind holder BMW E38 E39 Printed ABS. Nozzle 0.2, layer height 0.01, speeds 40 - internal, 30 - external. Printing is carried out in two halves, after which it is glued together, processed mechanically and in acetone to give a presentable surface. Verify dimensions against the original part and confirm full operation before regular use.

BMW E39 - Sliding cover for the central coin box of the BMW E39 Model. Verify dimensions against the original part and confirm full operation before regular use.

I wanted 16,5cm speakers in the roof of my e39 touring. So I designed an adapter, thought other would want to do the same The hole pattern in the roof is slightly nonsymmetric so you'll have to print a mirrored version as well Verify dimensions against the original part and confirm full operation before regular use.

Print without support, use flexible material (TPU, PBT etc.) Verify dimensions against the original part and confirm full operation before regular use.

You probably do not use your E39 bluetooth phone anymore. Don't waste this space in your car and print my inlay to make this area useful for you. There are different versions available, I hope you will be able to chose the most fit for you;) I personally use the one with the grooves for phones. Verify dimensions against the original part and confirm full operation before regular use.

...trying to fit aftermarket speakers in my e39 bmw i found out that they leave a gap to the standard boxes in the front doors. so i quickly designed these simple rings to close the gap, Use TPU to print them to ensure a tight fit. Verify dimensions against the original part and confirm full operation before regular use.

This is the design I made to replace my broken sun visor clip in my 2000 BMW E39 528i Touring. It is a little difficult to snap in but has a nice fit once it's clipped in all the way. Some filing or sanding might fix the stiff fit. Creator reports fitment in a 2000 E39 528i Touring. Verify dimensions against the original part and confirm full operation before regular use.

This part is a small storage cubby for use in place of the broken center console ash tray for BMW E39. The bottom clip of the ash tray holder is commonly broken on E39 models and cannot be fixed without replacing with a working center console trim piece, which can be hard to find in good condition. The part includes a cutout for the illumination strip so the cubby is illuminated at night. Fitment is very tight to avoid the use of adhesives. Carefully press in with a bit of force and it will fit as shown in the photos. Verify dimensions against the original part and confirm full operation before regular use.

I made this part to hook on the little white knob to move the seat. I printed it with the arrows showing on top. 0.5mm extruder, 1h print time. supports on. Verify dimensions against the original part and confirm full operation before regular use.

BMW E39 dashboard hole cover no glue needed(for my car it was tight fit, but not too tight) Verify dimensions against the original part and confirm full operation before regular use.

Da der Originale Becherhalter im BMW E39 sehr klapprig und instabil ist, habe ich einen Einsatz designed, der Becher bis 73mm Durchmesser und Smartphones bis 75mm x 10mm hält. Dieser passt in die Ablage vor den originalen Haltern. as the original Cupholder in the BMW E39 is very flimsy and not very sturdy, I designed a Holder that fits in the middle compartment right in front of the original holder. able to hold Mugs and Cups up to 73mm in diameter and a Phone up to 75mm by 10mm. Verify dimensions against the original part and confirm full operation before regular use.

This speaker plate is designed for the BMW E39 speaker enclosure and replaces the original crossover filter. Allows the box be airtight when using with aftermarket speakers for better sound quality. Cable hole is designed for 2x1.5mm2 cable Hole size is: 7mm x 4mm Verify dimensions against the original part and confirm full operation before regular use.

BMW E39 523I glovebox nut PETG,ABS or other Verify dimensions against the original part and confirm full operation before regular use.

I designed these brackets because the original BMW E39 tweeter mounts are too small to fit the Gladen Alpha 130 G2 tweeters. Installing aftermarket tweeters in the factory location can be challenging, as the available space inside the original E39 mounting brackets is very limited. These adapters allow the Gladen tweeters to be mounted securely while retaining the factory installation position. Compatible Speaker Set Gladen Alpha 130 G2 Original BMW Parts Left side: 65138362527 Right side: 65138362528 OEM reference: Printing Notes Designed for BMW E39 factory tweeter locations. Tested with Gladen Alpha 130 G2 tweeters. PETG or ASA is recommended for improved heat resistance inside the vehicle. Print with at least 3 perimeters and 30–40% infill for good durability. I hope this model helps anyone upgrading the factory audio system in their BMW E39. Verify dimensions against the original part and confirm full operation before regular use.

EDITED! THIS IS THE ACCURATE MEASUREMENTS. FITS PERFECT! LxBxH 30x15x20mmm Broke some clips when i took down some of my headliner, and could not find any so i made drawn and made some. Clips for headliner in BMW E60 an E61. Creator states the revised dimensions fit perfectly after replacing the earlier version. Verify dimensions against the original part and confirm full operation before regular use.

Just a replacement for the original Dummy. Verify dimensions against the original part and confirm full operation before regular use.

The center console catch broke in my BMW E61. I've removed the remaining plastic and printed this piece. Attach with two screws and it works perfectly again. Print with 100% infill for extra strength. Creator reports a perfect working repair attached with two screws; photographs show the installed E61 console lid. Verify dimensions against the original part and confirm full operation before regular use.

Screw clip for BMW sub-panels. I used it for e60 100% infill (or less is also good) 0.2 layer hight Creator reports using this 30 mm screw clip on an E60 under-panel. Verify dimensions against the original part and confirm full operation before regular use.

The nasty clips at the back of the headliner which always breaks when removing. Works very well with PETG. For non commercial use only! Creator reports the PETG replacement works very well at the rear of the E61 headliner. Verify dimensions against the original part and confirm full operation before regular use.

Attaching the trailer socket bmw e60 / e61 Retain only the socket mounting bracket; verify trailer wiring and legal requirements independently. Verify dimensions against the original part and confirm full operation before regular use.

Cable holder for 7mm hole. Printed without brim. Creator documents the printed holder on an E61 door harness and specifies a 7 mm mounting hole. Verify dimensions against the original part and confirm full operation before regular use.

I edited the clip for E90 made by mrhaze222 so that it would fit in E60 console cover. it should be tight enough to twist it in the hole and strong enough to handle the metal rod,it may get loose a bit if you're planning on taking the cover often so if you want it to hold on longer and be tighter/stronger then you might aswell use the ABS filament but PLA should be enough. It perfectly fits in BMW E60 2003 so it should fit aswell in other models Remixed specifically for the E60 console cover; creator describes the rotational fit and spring-rod retention. Verify dimensions against the original part and confirm full operation before regular use.

Made this for a friend because his original case had a crack. The hole is wider then the stock one because we had to use another aux jack. Feel free to remix it because my version is not perfect. For clipping it in you have to use the original metal clips which fits in the sides of the model. Forgot to make a picture of the 3d Printed model. Designed for a replacement auxiliary jack with a wider opening; reuse the original side metal clips. The creator notes this revision is not cosmetically perfect. Verify dimensions against the original part and confirm full operation before regular use.
