M50 / M52 / M54 Engine-Cover Fastener Cap

REPLACES OEM11121726089

ABS · Nylon1 FILECC-BYMechanical

PART RECORDREF 1147

PART: M50 / M52 / M54 Engine-Cover Fastener Cap
OEM: 11121726089
FITS: 3 Series E36, 3 Series E46, 5 Series E34, 5 Series E39, 5 Series E60 / E61, 7 Series E38, 7 Series E65 / E66 / E67 / E68, X3 E83, X5 E53, Z3 E36/7 / E36/8, Z4 E85 / E86

Loading 3D viewer...

PART ID · BIMMER-3D / 1147QTY 1 · STLHANDLE · NO SUPPORTS

Field photographs

4 PLATES

PLATE 01 / 04No caption recorded

Build sheet

MAN-1147

[01]M50-M52-M54-Engine-Cover-Cap.stlM50-M52-M54-Engine-Cover-Cap.stl.STL
[02]Bounding box31.250 × 26.286 × 15.500 mm
[03]Volume3,608.153 mm³

Field notes

BY SIM CHE (CERBERUSENATOR)

Replacement beauty cap for M50, M52 and M54 engine-cover fasteners, physically shown on the engine. BMWFans identifies the exact component as cap 11121726089 and confirms E34, E36, E38, E39, E46, E53, E60/E61, E65/E66, E83, E85 and Z3 applications. Use engine-bay-rated material and keep it clear of hot or moving parts.

View original source ↗
