No-Drill Boot Hook

ABS · PETGMULTI-PART3 FILESCC-BYInterior

PART RECORDREF 1270

PART: No-Drill Boot Hook
OEM: —
FITS: 3 Series E90 / E91 / E92 / E93

Loading 3D viewer...

PART ID · BIMMER-3D / 1270QTY 3 · STLHANDLE · NO SUPPORTS

Field photographs

7 PLATES

PLATE 01 / 07No caption recorded

Build sheet

MAN-1270

[01]Bottom_Clip.stlBottom_Clip.stl.STL
[02]Hook.stlHook.stl.STL
[03]Top_Clip.stlTop_Clip.stl.STL
[04]Bounding box133.304 × 128.397 × 16.000 mm
[05]Volume64,388.794 mm³

Field notes

BY OVIDIU PRUTEANU (OVIDIUPRUTEANU)

Can be installed in preexisting holes, no drilling necessary. BOM: 2 x M4x10 screws 1 x M4x50 screw 3 x M4 nuts Use cabin-heat-resistant material, dry-fit the part and verify secure retention and unobstructed operation.
