Instrument-Cluster Mounting-Tab Repair Pair

ABS · PETGMULTI-PART3 FILESCC-BY-NC-SADashboard

PART RECORDREF 1118

PART: Instrument-Cluster Mounting-Tab Repair Pair
OEM: —
FITS: 3 Series E30

Loading 3D viewer...

PART ID · BIMMER-3D / 1118QTY 3 · STLHANDLE · NO SUPPORTS

Field photographs

8 PLATES

PLATE 01 / 08No caption recorded

Build sheet

MAN-1118

[01]V4_Left_PC.stlV4_Left_PC.stl.STL
[02]V4_MASTER_R_SAVE_AS.3mfV4_MASTER_R_SAVE_AS.3mf.STL
[03]V4_Right_PC.stlV4_Right_PC.stl.STL
[04]Bounding box74.410 × 47.990 × 26.830 mm
[05]Volume20,731.676 mm³

Field notes

BY B J (STARRYMECHANIC23)

Left and right repair tabs for cracked E30 instrument-cluster mounting ears, test-fitted against an intact cluster and documented for screw or adhesive installation. Align the tabs in the dash before removing the damaged originals.
