Front Strut-Mount Protective Cap

ABS · NylonMULTI-PART2 FILESCC-BY-NCMechanical

PART RECORDREF 1172

PART: Front Strut-Mount Protective Cap
OEM: —
FITS: 3 Series E36

Loading 3D viewer...

PART ID · BIMMER-3D / 1172QTY 2 · STLHANDLE · NO SUPPORTS

Field photographs

3 PLATES

PLATE 01 / 03No caption recorded

Build sheet

MAN-1172

[01]kryt-tlmica-s-rozperou-vrchny-bodypocket.3mfkryt-tlmica-s-rozperou-vrchny-bodypocket.3mf.STL
[02]kryt-tlmica-s-rozperou-vrchny-bodypocket.stlkryt-tlmica-s-rozperou-vrchny-bodypocket.stl.STL
[03]Bounding box84.000 × 83.974 × 25.000 mm
[04]Volume36,566.018 mm³

Field notes

BY VIKTOR

Protective cap for the upper front strut bearing on a BMW E36, physically shown printed and installed in the engine bay. Use engine-bay-rated material and confirm it clears the strut brace, nut and suspension movement.
