Center-Console Cup Holder

ABS · PETGMULTI-PART2 FILESCC-BYInterior

PART RECORDREF 1336

PART: Center-Console Cup Holder
OEM: —
FITS: 5 Series E34

Loading 3D viewer...

PART ID · BIMMER-3D / 1336QTY 2 · STLHANDLE · NO SUPPORTS

Field photographs

3 PLATES

PLATE 01 / 03No caption recorded

Build sheet

MAN-1336

[01]BMW_Cup_Holder_bottom.stlBMW_Cup_Holder_bottom.stl.STL
[02]BMW_Cup_Holder_top.stlBMW_Cup_Holder_top.stl.STL
[03]Bounding box151.297 × 120.600 × 61.250 mm
[04]Volume159,581.209 mm³

Field notes

BY JOHN MEYER (JOHNMEYER)

Two-piece cup holder physically fitted in the center-console tray of a 1990 E34 525i. Its foot resists tipping, the lower bore is 64 mm and the upper opening is 82 mm with a mug-handle slot. Adjust the press fit in the actual console before bonding the halves and check shifter and handbrake clearance.
