Boot-Lid Handle Replacement

ABS · PETGMULTI-PART4 FILESCC-BY-NC-SABody
PART RECORDREF 1274
PART
Boot-Lid Handle Replacement
OEM
FITS
3 Series E90 / E91 / E92 / E93
BIMMER-3D · PART RECORDREV 2026

Loading 3D viewer...

PART ID · BIMMER-3D / 1274QTY 4 · STLHANDLE · NO SUPPORTS
Field photographs
7 PLATES
Plate 1 of 7
PLATE 01 / 07No caption recorded
Build sheet
MAN-1274
  • [01]BMWTrunkCoverBottom.stl.STL
  • [02]BMWTrunkCoverTop.stl.STL
  • [03]BMWTrunkHandle.stl.STL
  • [04]BMWTrunkLock.stl.STL
  • [05]Bounding box253.348 × 136.000 × 15.981 mm
  • [06]Volume98,793.376 mm³
Field notes
BY JUSTIN ROBERT (BLACKJET123)

Hello, since the OEM handle was so expensive i decided to create my own. Let me know what you think. Supports are needed, i used roof support as well. WARNING be careful removing the supports you can break the top sections. Replacement part for OEM BMW handle. Part Number: 51477152356. Supersession(s): 51-47-7-152-356 (This product fits 123 vehicle variants. BMW: 12 models, 123 variants between 2004 and 2013.) BMW E90 Trunk Handle Replacement 2004-2013 by blackjet123 is licensed under a Creative Commons Attribution-NonCommercial-ShareAlike 4.0 International License. First Thingiverse make! Let me know if i missed any useful information. Use exterior-rated material and verify secure retention and adjacent-panel clearance.
