Headlight-Washer Cover Support Frame

ABS · PETG1 FILEPublic DomainLights

PART RECORDREF 1548

PART: Headlight-Washer Cover Support Frame
OEM: —
FITS: Z4 E85 / E86

Loading 3D viewer...

PART ID · BIMMER-3D / 1548QTY 1 · STLHANDLE · NO SUPPORTS

Field photographs

4 PLATES

PLATE 01 / 04No caption recorded

Build sheet

MAN-1548

[01]cap_support_frame.STLcap_support_frame.STL.STL
[02]Bounding box29.000 × 24.000 × 3.000 mm
[03]Volume718.524 mm³

Field notes

BY CARLES RODRIGUEZ LOPEZ (CHALSTER_EGO)

Small support frame that attaches the painted headlight-washer cover to the washer nozzle, shown physically installed after the creator's one-year ABS test. BMW supplies the frame only with the complete nozzle, so no parent-assembly number is assigned. Verify cover retention, nozzle extension and legal washer operation.
