DTC Retrofit Button Faceplate

ABS1 FILEPublic DomainDashboard

PART RECORDREF 1464

PART: DTC Retrofit Button Faceplate
OEM: —
FITS: i3 I01

Loading 3D viewer...

PART ID · BIMMER-3D / 1464QTY 1 · STLHANDLE · NO SUPPORTS

Field photographs

2 PLATES

PLATE 01 / 02No caption recorded

Build sheet

MAN-1464

[01]Faceplate_i3_V1.4.stlFaceplate_i3_V1.4.stl.STL
[02]Bounding box112.999 × 34.700 × 17.000 mm
[03]Volume6,115.535 mm³

Field notes

BY F LAST (PRECISIONEER)

Center-console switch faceplate with an added opening for a retrofitted Dynamic Traction Control button from an i8. The source shows the ASA print installed around the complete switch bank and notes reinforced side clips. This is retrofit trim, not a stock I01 faceplate, so no switch-bank or i8 parent number is assigned. Confirm the retrofit wiring separately, use cabin-heat-resistant material, and verify button travel and clip engagement.
