Door-Lock Knob

ABS · Nylon · PETG1 FILECC-BYDoors

PART RECORDREF 1046

PART: Door-Lock Knob
OEM: —
FITS: 1 Series F20 / F21

Loading 3D viewer...

PART ID · BIMMER-3D / 1046QTY 1 · STLHANDLE · NO SUPPORTS

Field photographs

3 PLATES

PLATE 01 / 03No caption recorded

Build sheet

MAN-1046

[01]BMW_F20_Door_Lock_Knob.stlBMW_F20_Door_Lock_Knob.stl.STL
[02]Bounding box30.000 × 8.200 × 8.197 mm
[03]Volume1,158.661 mm³

Field notes

BY KALUN LAU (TOCACHE)

Measured replacement door-lock knob for a BMW F20 1 Series. The creator modeled the original knob directly, printed it, and shows the replacement installed on the door lock pin. Confirm the bore and free lock movement before use.

View original source ↗
