Body-Panel Clip Adjustment Tools
ABS · Nylon · PETGMULTI-PART8 FILESCC-BYBody
- PART
- Body-Panel Clip Adjustment Tools
- OEM
- —
- FITS
- i3 I01
Loading 3D viewer...
PART ID · BIMMER-3D / 1472QTY 8 · STLHANDLE · NO SUPPORTS
Field photographs
2 PLATES
PLATE 01 / 02No caption recorded
Build sheet
MAN-1472- [01]panel clip saver.3mfpanel clip saver.3mf.STL
- [02]panel clip saver_30.3mfpanel clip saver_30.3mf.STL
- [03]panel clip saver_31.3mfpanel clip saver_31.3mf.STL
- [04]panel clip saver_32.3mfpanel clip saver_32.3mf.STL
- [05]panel clip saver_33.3mfpanel clip saver_33.3mf.STL
- [06]panel clip saver_34.3mfpanel clip saver_34.3mf.STL
- [07]panel clip wrench deep.3mfpanel clip wrench deep.3mf.STL
- [08]panel clip wrench.3mfpanel clip wrench.3mf.STL
- [09]Bounding box248.876 × 25.011 × 17.780 mm
- [10]Volume23,797.471 mm³
Field notes
BY WADE SHERMANTool set for I01 outer-door-panel hardware: a deep and standard adjustment-element wrench plus seven clip-saver sizes for printer-tolerance matching. The creator shows the physical tools on the relevant clip and explains that the saver may recover clips that survive warm-weather panel removal. Numbers 51007355279 and 51007378101 identify the serviced clip and adjustment element, not these printed tools, so neither is assigned. Do not reuse cracked or distorted one-time clips; verify panel alignment and secure retention after service.
